September 9, 1997                             MAST 634               Lecture II: Hydrothermal Vents

Important Points of Last Lecture (9/4/97)

Molecular tools for identifying organisms
ribosomal RNA
Three Kingdoms: Eukarya, Bacteria, and Archaea
Review
          Ribosome structure
          Function of mRNA, tRNA, & rRNA in protein synthesis
          Base composition and pairings in DNA and RNA
                A-T, G-C, A-U, G-C

Form of primary production: chemoautotrophs

Can think of all life as redox reactions

                                                      e^- donor         e^- acceptor
       Animals (heterotrophs):    C₆H₁₂O₆ + 6O₂ = 6CO₂ + 6H₂O
       Chemo lithotrophs      :        H₂A + O₂ = A + H₂O

A bit more complicated than that
          energy ATP
          reducing power NAD(P)H (=NADPH or NADH)
                    Necessary for reducing compounds
                            E.g. CO₂ ---->  ----> C₆H₁₂O₆

                                                  C source     e^- source     Energy
            Heterotrophs                   organics         --->          --->
            Photoautotrophs                 CO₂          H₂O           light
           Chemoautotrophs                CO₂              inorganic compounds
           Chemolithotroph
           Photoorganotrophs              CO₂        organics        light

What are chemoautotrophs?
          bacteria
          archaea
very specialized; cannot use organic compounds
first organisms on earth?

         Sulfide-oxidizing bacteria

First note: H₂S = HS^- + H⁺ = S^2- + 2H⁺
        pka        7.0             13.0



So, at pH 8.0 (pH of Seawater) mostly HS^-

                                                                (delta)  G°´
                           HS^- + 20₂ = SO₄^2- + H⁺           -794
            S^o + 1½O₂ + H₂O = SO₄^2- + 2H⁺          -585

                                               Oxidation State
                                       HS^-                    -2
                                       S^o                  0
                                       SO₄             +5

Some important examples
          Nitrification
                NH₄⁺ ----> NO₂^- ---->NO^-₃

             Ammonium     nitrite          nitrate
oxidation      -3             +3              +5
state

     Important in
          soils:
         ocean:




     Common traits: redox reaction

          1. O₂ is e^- acceptor
          2. Inorganic compound e^- donor

     Compound must be "reduced", i.e. have e^-

              Possible           Not possible
                  HS^-                  SO₄^2-
                 NH₄⁺               NO₃^-
                 Fe²⁺                 Fe³⁺

How to calculate energy yield?      p 434-441
                                                      Chap. 3

Gibbs free energy
     (delta)  G   =  (delta)  H         -T(delta)S
                                  |                     |
                            Enthapy        Entropy; change in order

(delta) G > O; change in heat endergonic; not spontaneous
(delta) G = O; forward and backward reaction balance equilibrium
(delta) G < O; exergonic; spontaneous reaction

Redox reaction
    see handout

Example:     NO₂^- oxidation with O₂

Divide into half-reactions
          ⁺³NO₂^- ----> ⁺⁵NO₃^- + 2e^-
         ½ O₂ + 2e^- ----> H₂O

Look for reduction potential in table

                                                               E^o´  (V)
           ½O₂ + 2H⁺ + 2e = H₂O              + 0.815
     NO₃^- + 2H⁺ + 2e = NO₂^- + H₂O      + 0.42

Notes
     Relative to 2H⁺ + 2e^- = H₂
     E^o´   : std biochemical state
     E^o´   : std chemical state
     e^- on left; reduction

sum of half reactions:    (delta) E^o´   = E^o´   _{e acceptor}  - E^o´   _{e donor}

In this example
          acceptor: O₂
          donor : NO₂
    (delta) E^o´   = 0.815 - (+0.42)
             = +0.39 V

How to relate to (delta)   G?
              (delta) G = -n F E derivation in book
                         N = number of electrons
                         F = Faraday's const.

Note: if E > O, then (delta) G <O, i.e. rx goes!
     so, to decide if X and Y are donor or accept, see which has larger E^o´   (potential)

0.39 V * 96,494 J V^-1 mol^-1 *2 = 75270 J mol^-1
                                                 = 75.3 kJ mol^-1

Is this a lot?    No, small compared to oxidative phosphorylation
                   C₆H₁₂O₆ + 6O₂ = 6CO₂ + 6H₂O -2823K J mol^-1

See page 43

NADH + ½ O₂ = NAD⁺ + H₂O
                             (delta) G^o = -218 kJ mol^-1

Again, energy obtained from oxidation of NO₂^- small to that requred to synthesize NADH
Need more NO₂^- than expected for NADH synthesis, because also need to synthesize ATP

Reduction of 1 NAD requres 5 NO₂^-

How does microbe get reducing power and energy?

Reverse e^- flow
     Details not important, but main features are

1. Oxidation of NO₂^- creates
     - Proton gradient
     - charge gradient
2. Series of cytochromes mediates e^- flow like in respiration.






Proton-motive force

(delta) G = 2.3 RT[pH_In^- pH_out] + ZF (delta and psi symbols missing)
                                                                           |
                                                             Membrane potential

Mitochondria

          (delta)pH = 0.75 higher outside
        (delta & ps)= 0.168 V

~ 210,00 V cm^-1 over 80A

o.:(delta)G = -21.5 kJ mol^-1

Bottom Line
     not much energy in oxidizing inorganic compounds
     see table on pagae 284 in Gottschalk (on reserve)

Importance of symbiotic chemoautotrophic Bacteria at Hydrothermal vents

Vent communities supported by chemoautotrophy
     - novel; usually phototrophy
     - more novel: symbiosis

First Example
     Colleen Cavanaugh ~ 1980

Phylum Vestimentifera
     Riftia pachyptila

Evidence of symbiosis
     bacteria-like particles
     presence of lipo polysaccharide (LPS)
          -endotoxin
          -unique to G - bacteria

enzyme unique to autotrophy
               Rubisco: CO₂-fixing enzyme
              other enzymes
              APS - reductase
              ATP - sulfurylase

But impossible to culture symbiont

     How to study
     ori ginal study on tube worm
     Dan Distel (Norm Pace's lab) (1988)

               Isolate RNA

                      |         Reverse transcriptase
                      |           (Originally from NA virus)
                      |                     David Baltimore, Nobel Prize ~ 1975
                      |             Using primers specific to 16S RNA

              16S rDNA

                       |

              Sequence

Results
     each animal species had a different symbiont

Note limitations
     1. Difficult to work with RNA
     2. Reverse transcriptase linear increase in DNA; used with other primers

Distel and Cavanaugh (1994)

How do different types of symbiontic bacteria compare?

                 DNA

                     |        PCR with "universal" primers for 16S

             16S rDNA

                     |        Clone into "TA vector"

Separate clones, each with separate 16S gene

What is cloning?

Putting "foreign" DNA into a self reproducing vector which in turn goes into host (usually bacteria)

See p 901 of book for overview of cloning

One plasmid + insert ----> one bacterium ----> one colony (many bacteria) on

Cloning PCR products
     example where insert is "made" by PCR
     other cases where insert comes directly from organisms

What does PCR product look like?       Theory    "blunt" ends                                    0.1 kb - 10 k kb

In fact:



                       Design vector with T



                                    Need to "cement" vector-insert with ligase

What did they find?
     1. Chemoauto trophic symbionts very different from methanotrophs, although both proteobacteria
     2. Some similarity between symbionts and known methanotrophs -- evidence that symbiont is a                   methanotroph.
